1.2 Target Audience and Use Cases

The Aorus Z790 Elite AX is tailored for gamers, content creators, and PC enthusiasts seeking a balance between performance and affordability. Its robust features make it ideal for high-end gaming rigs and professional workstations. The motherboard supports overclocking, appealing to those who want to push their hardware limits. Additionally, its Wi-Fi 7 and high-speed USB ports cater to streamers and professionals needing reliable connectivity. For casual users, it offers a stable and future-proof platform for everyday computing. Whether building a powerful gaming PC or a versatile workstation, the Aorus Z790 Elite AX is a reliable choice for various computing needs.

Installation Guide

The Aorus Z790 Elite AX installation guide provides step-by-step instructions for unboxing, motherboard preparation, CPU installation, RAM, storage, PSU, and front panel setup. Follow carefully.

2.1 Unboxing and Preparing the Motherboard

Unboxing the Aorus Z790 Elite AX motherboard requires careful handling to avoid damage. Inspect the package for any visible damage before opening. Once unboxed, ground yourself by touching a metal object or use an anti-static strap to prevent static discharge. Prepare the necessary tools, such as screws and cable ties. The motherboard comes with accessories like SATA cables, Wi-Fi antennas, and a user manual. Handle the motherboard by the edges to avoid touching sensitive components. Before installation, ensure all components are accounted for and the motherboard is free from packaging materials. Refer to the manual for detailed preparation steps.

• Ground yourself to prevent static damage.
• Inspect the motherboard for damage.
• Prepare tools and accessories.
• Handle the motherboard by the edges.

2.2 Installing the Motherboard in a PC Case

Before installing the Aorus Z790 Elite AX, ensure the PC case supports the ATX form factor. Prepare the case by removing unnecessary panels and aligning the motherboard stand-offs with the case mounting holes. Gently place the motherboard into the case, ensuring it fits securely. Use screws to fasten it to the stand-offs, tightening evenly to avoid warping. Connect the front panel headers, USB ports, and other case connectors to the motherboard. Route cables neatly for optimal airflow and aesthetics. Double-check all connections before closing the case. Handle the motherboard by the edges to prevent damage, and ensure proper grounding to avoid static discharge.

• Ensure case compatibility with ATX form factor.
• Align stand-offs and secure the motherboard.
• Connect front panel and USB ports.
• Route cables neatly for airflow.
• Handle with care to avoid damage.

2.3 CPU Installation and Socket Preparation

Prepare the CPU socket by lifting the lever and aligning the CPU pins with the LGA 1700 socket. Ensure the CPU is handled by the edges to prevent damage. Gently insert the CPU, making sure it aligns with the socket’s pins. Secure the CPU by lowering the lever until it clicks. Apply a thin layer of thermal paste to the CPU die (if not pre-applied). Install the CPU cooler, ensuring even pressure. Connect the CPU power cable to the motherboard’s EPS connector. Finally, update the BIOS to the latest version for optimal CPU compatibility and performance. Always ground yourself or use an anti-static wrist strap to prevent static damage.

• Lift the socket lever and align the CPU pins.
• Gently insert and secure the CPU.
• Apply thermal paste if necessary.
• Install the CPU cooler and connect power.
• Update BIOS for compatibility.

2.4 RAM and Storage Installation

Install RAM by aligning the notches on the DIMM with the slots. Gently push the RAM into the slot until it clicks. For storage, connect SATA drives to the SATA ports and M.2 NVMe SSDs to the M.2 slots. Ensure the storage devices are properly secured to the motherboard. Configure RAID or AHCI mode in the BIOS if required. Install your operating system to the selected storage device. Dual-channel memory configuration is supported for enhanced performance. Always handle components by the edges to avoid static damage. Consult the manual for specific slot configurations and compatibility.

• Align RAM notches with DIMM slots.
• Secure SATA and M.2 storage devices.
• Configure storage settings in BIOS.
• Handle components carefully to prevent damage.

2.5 Connecting the Power Supply Unit (PSU)

Connect the PSU to the motherboard by locating the 24-pin ATX power connector near the right edge. Align the PSU cable with the motherboard connector, ensuring it fits securely. Gently push until it clicks. Next, connect the 8-pin EPS cable to the CPU power connector, typically located near the CPU socket. Ensure both connectors are firmly seated to avoid power issues. If your PSU has additional PCIe power connectors, connect them to the GPU. Double-check all connections for proper alignment and security. Finally, connect the PSU to a power source and ensure the power switch is turned on. Verify power rails in BIOS if necessary.

• Connect the 24-pin ATX cable to the motherboard.
• Secure the 8-pin EPS cable near the CPU socket.
• Connect PCIe power cables to the GPU if required.
• Ensure all connections are secure and properly aligned.

2.6 Setting Up the Front Panel Connectors

Locate the front panel header on the motherboard, typically labeled as F_PANEL. Connect the power switch, reset switch, HDD LED, and power LED cables to their respective pins. Use the provided cable or adapter for proper alignment. Ensure the USB ports and audio jacks from the case are connected to the appropriate headers. Securely plug in the HD audio cable for front panel audio functionality. Double-check each connection for correct orientation and alignment to avoid damage. Refer to the motherboard manual for specific pin layouts and configurations. Once connected, test the front panel components to ensure proper functionality before closing the PC case.

• Connect power and reset switches to their designated pins.
• Attach HDD and power LEDs to their respective headers.
• Secure USB and audio ports for front panel functionality.
• Verify all connections for proper alignment and security.

BIOS Setup

Access the BIOS by pressing Del or F2 during startup. Navigate through menus to configure settings like boot order, overclocking, and fan controls. Save changes before exiting.

3.1 Navigating the BIOS Interface

Access the BIOS by pressing Del or F2 during system startup. The BIOS interface is user-friendly, with menus for system status, advanced settings, and overclocking. Use arrow keys to navigate and Enter to select options. The Mouse feature allows point-and-click navigation for ease. Key sections include Main, Advanced, Performance, and Boot. Customize settings like time, boot order, and fan profiles. Save changes with F10 or exit without saving using Esc. Familiarize yourself with shortcuts for efficient BIOS management.

3.2 Configuring Boot Settings and Order

Access the BIOS and navigate to the Boot tab to configure boot settings. Set the Boot Order by prioritizing your preferred boot device, such as an SSD or HDD. Use the arrow keys to rearrange the list. Enable Secure Boot for enhanced security, ensuring only trusted devices boot. Select UEFI mode for modern systems or Legacy for older operating systems. Save changes using F10 and exit. Properly configuring boot settings ensures your system starts efficiently and securely. Always verify boot order after installing new storage devices to avoid boot issues. This step is crucial for smooth system operation.

3.3 Overclocking Basics in BIOS

Access the BIOS by pressing DEL or F2 during boot. Navigate to the M.I.T. (Motherboard Intelligent Tweaker) section for overclocking. Adjust the CPU Ratio or Base Clock to increase performance. Modify VCore Voltage carefully to stabilize overclocks. Monitor temperatures and system stability. Save changes with F10 and restart. Overclocking voids warranty and risks system instability. Use with caution and ensure proper cooling. Gigabyte’s BIOS provides intuitive tools for beginners and advanced users. Always stress-test your system after overclocking to ensure stability. This section covers basic BIOS overclocking; advanced settings are discussed in later sections. Proceed with care to avoid damage. Regular monitoring is essential for long-term system health.

3.4 Adjusting Memory Settings

Access the BIOS and navigate to the M.I.T. section. Under Memory Settings, enable XMP profiles for optimal DDR4 performance. Adjust Memory Timing for stability or performance. Set Memory Voltage to recommended levels. Enable Dual Channel Mode for improved bandwidth. Save changes and restart. Test system stability with stress-testing tools. Incorrect settings may cause instability. Refer to the manual for detailed timing parameters. Gigabyte’s BIOS offers intuitive controls for memory configuration. Ensure compatibility with installed RAM modules. Overclocking memory voids warranty. Monitor system temperatures after adjustments. This section focuses on memory settings; advanced tuning is covered elsewhere. Always prioritize stability for long-term system reliability. Proceed with caution.

3.5 Configuring Storage Settings

In the BIOS, navigate to the Advanced tab and select Storage Settings. Here, you can configure SATA and NVMe drives. Enable SATA Mode (AHCI recommended) for drives. For NVMe SSDs, ensure PCIe mode is selected. Configure RAID if desired. Set the Boot Order to prioritize your storage device. Save changes and exit BIOS. Connect drives to the appropriate ports on the motherboard. The Aorus Z790 Elite AX supports multiple M.2 slots for high-speed storage. Refer to the manual for detailed instructions. Ensure firmware is updated for optimal performance. Always back up data before making changes. This section focuses solely on storage configuration. Proceed carefully.

3.6 Setting Up Fan Controls

Navigate to the Fan Controls section in the BIOS under the Advanced tab; Configure fan settings for optimal cooling. Select from predefined modes like Silent, Balanced, or Performance. Adjust fan curves based on temperature thresholds for custom control. Enable Smart Fan 5 for dynamic fan speed adjustments. Connect case fans to the motherboard’s fan headers, ensuring proper airflow. Refer to the manual for header locations. Use RGB Fusion software for synchronized lighting. Monitor temperatures in real-time. Adjust settings to balance noise and cooling performance; Save configurations before exiting BIOS. Regularly update BIOS for improved fan control features. This section focuses solely on fan setup. Follow guidelines carefully.

3.7 Saving BIOS Settings

After configuring your BIOS settings, navigate to the Exit tab. Select Save & Exit to apply changes. Confirm by pressing Enter or following on-screen prompts. The system will restart, saving all configurations. Ensure no unsaved changes are present before exiting. If prompted, confirm saving to avoid data loss. Your custom BIOS settings are now applied. For detailed instructions, refer to the Gigabyte Z790 Aorus Elite AX manual. Always save changes before exiting BIOS to preserve your customizations. This step ensures stability and optimal system performance. Follow BIOS guidelines carefully; Properly saved settings are crucial for system functionality.

Features and Specifications

The Aorus Z790 Elite AX supports 13th/12th Gen Intel CPUs, DDR4 memory, and features Wi-Fi 7, USB 3.2 Gen 2, and PCIe 5.0 for high-performance computing and connectivity.
